The installation of the aluminum door is closely related to the reserved size, and measurement errors will cause many subsequent problems. This article will specifically introduce the measurement method of aluminum doors.
When we measure the aluminum door, if there is a large error, it will cause the reserved size to be too large or too small, and thus cannot be installed. Only when the dimensions are accurate can the installation be carried out smoothly to ensure the safety of home doors. The following is the specific measurement method for aluminum doors.
1. Measurement of the width of the aluminum door opening
When measuring, we must pay attention to the level measurement, and repeatedly select five different points for measurement. After the measurement, select the smaller one of these five values (minus the door frame adjustment margin) as the extension dimension of the aluminum door frame, and its tolerance should be kept within -15~15mm. If the measured value of the five values is actually measured The error is above 20mm, then the door opening needs to be adjusted.
2. Measurement of the wall thickness of aluminum door opening
The same as the width measurement method mentioned above, the wall thickness measurement also needs to be kept in the horizontal direction, and five fewer points need to be selected for measurement, and the larger value of the measurement result is used as the wall thickness. If you need to paint the wall or have other decorations, then the thickness of the wall needs to be added to the thickness of the decoration material, and the tolerance range should be kept within the range of 0-5mm.
3. Measurement of the height of the aluminum door opening
The measurement of the height of the aluminum door opening needs to select more than three points to measure and use a lower value as the extension dimension, and the tolerance should be kept within -5~10mm, if the error between the three points measured is all within 10mm Above, the aluminum door needs to be adjusted at this time.
The measurement of aluminum door products needs to be done indoors after laying tiles or floors, and cleaning the ground before it can be used as a benchmark measurement. If the laying of the ground is not completed, a certain thickness must be left.
4. Measurement of the aluminum door leaf
The width of the door leaf: horizontally measure the empty distance inside the door frame, and select more than five measurement points to measure, the minimum of which is (minus the reserved gap) is the width of the door leaf.
The height of the door leaf: Vertically measure the empty distance inside the door frame, and select more than three measuring points to measure, the minimum value (minus the reserved gap) is the height of the door leaf.
Even if the error produced in the process of measuring the aluminum door is not obvious, it may cause certain safety hazards, so we must be cautious in the process of measuring. If you want to know more information related to aluminum doors after reading the above, you can contact us for more detailed solutions.
